Concrete panel and post retaining wall certified engineering details.



Technical specifications:

  • This certified engineering details is suitable for a sand site (site Class A in accordance with AS2870);
  • Maximum surcharge loading of 2.5kPa;
  • Maximum retained height 1500mm;



The retaining wall has been designed to withstand fence load over and will be adequate to support the wind loads imposed by 1800mm high post & rail fence (Colorbond fencing or similar), with max post spacing to be 2400mm; or an 1800mm high embedded fence.



Concrete panel and post retaining wall certified engineering details Perth
